Click on item to order
06-4896A
|
British Spares
Item No: 1 Currency: NZ
 | |||||
| Stock Code | Description | Price | Rec Qty | Stock | |
| 06-4896A | CONROD SET,NORTON,BILLET ALLOY | $822.82 | 1 | <1 |  |
| Hide | |||||
06-7828
|
British Spares
Item No: 2 Currency: NZ
| |||||
| Stock Code | Description | Price | Rec Qty | Stock | |
| 06-7828 | BOLT,CONROD,NORTON 650/750/850 | $19.41 | 4 | 10+ | |
| Hide | |||||
06-7827
|
British Spares
Item No: 3 Currency: NZ
| |||||
| Stock Code | Description | Price | Rec Qty | Stock | |
| 06-7827 | NUT,CONROD,NORTON 650/750/850 | $10.06 | 4 | 10+ | |
| Hide | |||||
More Info
|
British Spares
Item No: 4 Currency: NZ
| |||||
| Stock Code | Description | Price | Rec Qty | Stock | |
| More Info | Conrod Bearing Shell Set Sizes (1 set for 1 engine) | ||||
| 06-4285 | BIG END BEARING SHELL SET,NORTON 650-850, .000in. Undersize Crank Journals | $215.68 | 1 | 2 | |
| 06-4286 | BIG END BEARING SHELL SET,NORTON 650-850, .010in. Undersize Crank Journals | $215.68 | 1 | 2 | |
| 06-4287 | BIG END BEARING SHELL SET,NORTON 650-850, .020in. Undersize Crank Journals | $191.83 | 1 | 4 | |
| 06-4288 | BIG END BEARING SHELL SET,NORTON 650-850, .030in. Undersize Crank Journals | $215.68 | 1 | 3 | |
| 06-4289 | BIG END BEARING SHELL SET,NORTON 650-850, .040in. Undersize Crank Journals | $129.38 | 1 | 2 | |
| Hide | |||||
Note
|
British Spares
Item No: 5 Currency: NZ
| |||||
| Stock Code | Description | Price | Rec Qty | Stock | |
| Note: | Note:Bearing shells supplied as sets, see 4 | ||||
| Hide | |||||
060571
|
British Spares
Item No: 6 Currency: NZ
| |||||
| Stock Code | Description | Price | Rec Qty | Stock | |
| 060571 | CRANKSHAFT ASSEMBLED Not Stocked - click to email enquiry | ||||
| Hide | |||||
NM.23262
|
British Spares
Item No: 7 Currency: NZ
| |||||
| Stock Code | Description | Price | Rec Qty | Stock | |
| NM.23262 | CRANK-CHEEK T.S Not Stocked - click to email enquiry | ||||
| Hide | |||||
060542
|
British Spares
Item No: 8 Currency: NZ
| |||||
| Stock Code | Description | Price | Rec Qty | Stock | |
| 060542 | CRANK-CHEEK D.S Not Stocked - click to email enquiry | ||||
| Hide | |||||
06-0731
|
British Spares
Item No: 9 Currency: NZ
| |||||
| Stock Code | Description | Price | Rec Qty | Stock | |
| 06-0731 | FLYWHEEL Not Stocked - click to email enquiry | ||||
| Hide | |||||
06-7558
|
British Spares
Item No: 10 Currency: NZ
| |||||
| Stock Code | Description | Price | Rec Qty | Stock | |
| 06-7558 | DOWEL | $8.69 | 1 | 1 | |
| Hide | |||||
More Info
|
British Spares
Item No: 11 Currency: NZ
| |||||
| Stock Code | Description | Price | Rec Qty | Stock | |
| More Info | Available Separately Or As Kit | ||||
| 06-7534 | LOCKING PLATE NM2032 | $2.11 | 2 | 2 | |
| Note: | For Updated Kit Replacing Items 11-16, Use 06-7094 | ||||
| 06-7094 | CRANK STUD/NUT KIT,NORTON MK2 | $120.94 | 1 | 5 | |
| Hide | |||||
More Info
|
British Spares
Item No: 12 Currency: NZ
| |||||
| Stock Code | Description | Price | Rec Qty | Stock | |
| More Info | Available Separately Or As Kit | ||||
| 06-7553 | STUD | $2.84 | 2 | 7 | |
| Note: | For Updated Kit Replacing Items 11-16, Use 06-7094 | ||||
| 06-7094 | CRANK STUD/NUT KIT,NORTON MK2 | $120.94 | 1 | 5 | |
| Hide | |||||
More Info
|
British Spares
Item No: 13 Currency: NZ
| |||||
| Stock Code | Description | Price | Rec Qty | Stock | |
| More Info | Available Separately Or As Kit | ||||
| 06-7533 | NUT,CRANKSHAFT,CEI | $5.20 | 4 | 8 | |
| Note: | For Updated Kit Replacing Items 11-16, Use 06-7094 | ||||
| 06-7094 | CRANK STUD/NUT KIT,NORTON MK2 | $120.94 | 1 | 5 | |
| Hide | |||||
More Info
|
British Spares
Item No: 14 Currency: NZ
| |||||
| Stock Code | Description | Price | Rec Qty | Stock | |
| More Info | Available Separately Or As Kit | ||||
| 06-7535 | BOLT,CRANK,NORTON TWIN,CEI | $14.66 | 4 | 9 | |
| Note: | For Updated Kit Replacing Items 11-16, Use 06-7094 | ||||
| 06-7094 | CRANK STUD/NUT KIT,NORTON MK2 | $120.94 | 5 | | |
| Hide | |||||
More Info
|
British Spares
Item No: 15 Currency: NZ
| |||||
| Stock Code | Description | Price | Rec Qty | Stock | |
| More Info | Available Separately Or As Kit | ||||
| 06-7533 | NUT,CRANKSHAFT,CEI | $5.20 | 2 | 8 | |
| Note: | For Updated Kit Replacing Items 11-16, Use 06-7094 | ||||
| 06-7094 | CRANK STUD/NUT KIT,NORTON MK2 | $120.94 | 1 | 5 | |
| Hide | |||||
More Info
|
British Spares
Item No: 16 Currency: NZ
| |||||
| Stock Code | Description | Price | Rec Qty | Stock | |
| More Info | Available Separately Or As Kit | ||||
| 06-7835 | NUT,CRANKSHAFT,NORTON,CEI | $5.43 | 2 | 2 | |
| Note: | For Updated Kit Replacing Items 11-16, Use 06-7094 | ||||
| 06-7094 | CRANK STUD/NUT KIT,NORTON MK2 | $120.94 | 1 | 5 | |
| Hide | |||||
06-7600
|
British Spares
Item No: 17 Currency: NZ
| |||||
| Stock Code | Description | Price | Rec Qty | Stock | |
| 06-7600 | SCREW,CRANKSHAFT OILWAY | $6.16 | 1 | 3 | |
| Hide | |||||
06-7537
|
British Spares
Item No: 18 Currency: NZ
| |||||
| Stock Code | Description | Price | Rec Qty | Stock | |
| 06-7537 | TIMING PINION | $155.45 | 1 | 1 | |
| Hide | |||||
06-5675
|
British Spares
Item No: 19 Currency: NZ
| |||||
| Stock Code | Description | Price | Rec Qty | Stock | |
| 06-5675 | KEY,TIMING PINION,NORTON MK3 | $9.41 | 1 | 10+ | |
| Hide | |||||
06-7525
|
British Spares
Item No: 20 Currency: NZ
| |||||
| Stock Code | Description | Price | Rec Qty | Stock | |
| 06-7525 | TIMING PINION BACK PLATE | $17.05 | 1 | 1 | |
| Hide | |||||
06-7889
|
British Spares
Item No: 21 Currency: NZ
| |||||
| Stock Code | Description | Price | Rec Qty | Stock | |
| 06-7889 | TIMING PINION NUT-OIL WORM | $219.94 | 1 | 1 | |
| Hide | |||||
More Info
|
British Spares
Item No: 22 Currency: NZ
| |||||
| Stock Code | Description | Price | Rec Qty | Stock | |
| More Info | Camshafts available to suit standard or higher performance applications | ||||
| 06-1084 | CAMSHAFT,NORTON COMMANDO,STANDARD PROFILE | $803.11 | 1 | 1 | |
| 06-3536 | CAMSHAFT,NORTON COMMANDO, 2S COMBAT PROFILE Notes: Introduced for the 750cc Combat engine with more lift and duration and virtually equal overlap resulting in more power at the top end at the expense of bottom end torque. |
$569.25 | 1 | <1 | |
| 06-4858 | CAMSHAFT,NORTON COMMANDO, 4S PROFILE Notes: Advanced inlet timing compared with the 2S, while the exhaust timing remains the same. This yields more midrange power than the 2S. |
$543.38 | 1 | <1 | |
| Hide | |||||
06-1086
|
British Spares
Item No: 23 Currency: NZ
| |||||
| Stock Code | Description | Price | Rec Qty | Stock | |
| 06-1086 | THRUST WASHER,CAMSHAFT | $15.41 | 1 | 6 | |
| Hide | |||||
06-1077
|
British Spares
Item No: 24 Currency: NZ
| |||||
| Stock Code | Description | Price | Rec Qty | Stock | |
| 06-1077 | PINION,INT WITH BUSH,COMMANDO | $305.32 | 1 | 1 | |
| Hide | |||||
06-1079
|
British Spares
Item No: 25 Currency: NZ
| |||||
| Stock Code | Description | Price | Rec Qty | Stock | |
| 06-1079 | BUSH,INTERMEDIATE GEAR | $18.12 | 1 | 2 | |
| Hide | |||||
06-1078
|
British Spares
Item No: 26 Currency: NZ
| |||||
| Stock Code | Description | Price | Rec Qty | Stock | |
| 06-1078 | INTERMEDIATE GEAR SHAFT | $73.39 | 1 | 2 | |
| Hide | |||||
06-7690
|
British Spares
Item No: 27 Currency: NZ
| |||||
| Stock Code | Description | Price | Rec Qty | Stock | |
| 06-7690 | CIRCLIP | $1.87 | 1 | 5 | |
| Hide | |||||
06-1080
|
British Spares
Item No: 28 Currency: NZ
| |||||
| Stock Code | Description | Price | Rec Qty | Stock | |
| 06-1080 | CAMSHAFT SPROCKET | $107.08 | 1 | 2 | |
| Hide | |||||
06-5675
|
British Spares
Item No: 29 Currency: NZ
| |||||
| Stock Code | Description | Price | Rec Qty | Stock | |
| 06-5675 | KEY,TIMING PINION,NORTON MK3 | $9.41 | 1 | 10+ | |
| Hide | |||||
06-7774
|
British Spares
Item No: 30 Currency: NZ
| |||||
| Stock Code | Description | Price | Rec Qty | Stock | |
| 06-7774 | NUT,CAMSHAFT SPROCKET | $14.16 | 1 | 1 | |
| Hide | |||||
06-7689
|
British Spares
Item No: 31 Currency: NZ
| |||||
| Stock Code | Description | Price | Rec Qty | Stock | |
| 06-7689 | CHAIN,CAM,NORTON, ENDLESS | $47.20 | 1 | 7 | |
| Hide | |||||
06-1094
|
British Spares
Item No: 32 Currency: NZ
| |||||
| Stock Code | Description | Price | Rec Qty | Stock | |
| 06-1094 | TENSIONER SLIPPER,COMMANDO | $16.91 | 1 | <1 | |
| Hide | |||||
06-7575
|
British Spares
Item No: 33 Currency: NZ
| |||||
| Stock Code | Description | Price | Rec Qty | Stock | |
| 06-7575 | TENSIONER BACKING PLATE-THIN | $5.62 | 1 | 2 | |
| Hide | |||||
06-7576
|
British Spares
Item No: 34 Currency: NZ
| |||||
| Stock Code | Description | Price | Rec Qty | Stock | |
| 06-7576 | TENSIONER BACKING PLATE,THICK | $3.73 | 1 | 1 | |
| Hide | |||||
06-7509
|
British Spares
Item No: 35 Currency: NZ
| |||||
| Stock Code | Description | Price | Rec Qty | Stock | |
| 06-7509 | STUD | $1.45 | 2 | 4 | |
| Hide | |||||
06-7700
|
British Spares
Item No: 36 Currency: NZ
| |||||
| Stock Code | Description | Price | Rec Qty | Stock | |
| 06-7700 | WASHER | $0.53 | 2 | 5 | |
| Hide | |||||
06-7592
|
British Spares
Item No: 37 Currency: NZ
| |||||
| Stock Code | Description | Price | Rec Qty | Stock | |
| 06-7592 | NUT,TENSIONER STUD | $9.16 | 2 | 6 | |
| Hide | |||||
More Info
|
British Spares
Item No: 38 Currency: NZ
| |||||
| Stock Code | Description | Price | Rec Qty | Stock | |
| More Info | Piston Set Size Options ( Set Includes Two Pistons, Rings, Two Gudgeon Pins and Four Circlips) | ||||
| 06-7055 | PISTON SET,Norton Commando 750,73mm Standard Bore Size | $491.62 | 1 | 3 | |
| 06-7056 | PISTON SET,Norton Commando 750,73mm +.020in. oversize | $615.83 | 1 | 1 | |
| 06-7057 | PISTON SET,Norton Commando 750,73mm +.040in. oversize | $646.88 | 1 | 1 | |
| 06-7110 | PISTON SET,Norton Commando 750,73mm +.060in. oversize | $492.30 | 1 | 1 | |
| Hide | |||||
More Info
|
British Spares
Item No: 39 Currency: NZ
| |||||
| Stock Code | Description | Price | Rec Qty | Stock | |
| More Info | Supplied as set, refer to item 38 | ||||
| Hide | |||||
More Info
|
British Spares
Item No: 40 Currency: NZ
| |||||
| Stock Code | Description | Price | Rec Qty | Stock | |
| More Info | Rings sold as sets only | ||||
| R26260/000 | RING SET,NOR 750,73mm,STD | $ | 1 | <1 | |
| R26260/010G | RING SET,NORTON 750,73mm +.010in. oversize (NOS) | $120.75 | 1 | 3 | |
| R26260/020 | RING SET,NOR 750,73mm, 020 | $ | 1 | <1 | |
| R26260/040 | RING SET,NOR 750,73mm, 040 | $ | 1 | <1 | |
| R26260/060 | RING SET,NOR 750,73mm, 060 | $ | 1 | <1 | |
| R26260/080 | RING SET,NORTON 750,73mm +.080in. oversize | $132.83 | 1 | 5 | |
| Hide | |||||
More Info
|
British Spares
Item No: 41 Currency: NZ
| |||||
| Stock Code | Description | Price | Rec Qty | Stock | |
| More Info | Rings sold as sets only, refer to item 40 | ||||
| Hide | |||||
More Info
|
British Spares
Item No: 42 Currency: NZ
| |||||
| Stock Code | Description | Price | Rec Qty | Stock | |
| More Info | Rings sold as sets only, refer to item 40 | ||||
| Hide | |||||
06-0955
|
British Spares
Item No: 43 Currency: NZ
| |||||
| Stock Code | Description | Price | Rec Qty | Stock | |
| 06-0955 | GUDGEON PIN,NOR 750 | $19.31 | 2 | 5 | |
| Hide | |||||
70-6840
|
British Spares
Item No: 44 Currency: NZ
| |||||
| Stock Code | Description | Price | Rec Qty | Stock | |
| 70-6840 | CIRCLIP,PIST,HEPO,TRIPLE/COMMA | $1.18 | 4 | 4 | |
| Hide | |||||
06-7559
|
British Spares
Item No: 45 Currency: NZ
| |||||
| Stock Code | Description | Price | Rec Qty | Stock | |
| 06-7559 | SPRING,BREATHER | $5.72 | 1 | 4 | |
| Hide | |||||
06-7879
|
British Spares
Item No: 46 Currency: NZ
| |||||
| Stock Code | Description | Price | Rec Qty | Stock | |
| 06-7879 | DISC VALVE,BREATHER,TO '72 COM | $43.73 | 1 | 5 | |
| Hide | |||||
06-7526
|
British Spares
Item No: 47 Currency: NZ
| |||||
| Stock Code | Description | Price | Rec Qty | Stock | |
| 06-7526 | WASHER,SEALING T/S BEARING | $13.47 | 1 | 6 | |
